Key Features:
- 8-Axis Control System: Offers precise and synchronized winding operations for intricate coil designs, ensuring consistent quality and efficiency.
- Wire Compatibility: Supports wire diameters ranging from 0.025mm to 0.5mm, providing flexibility for a wide range of coil production needs.
- Enhanced Wire Spacing: Features a spindle distance of 54mm, enabling precise wire positioning and optimized coil designs.
- Robust Construction: Accommodates a maximum bone frame diameter of 30mm with a main shaft diameter of 10mm, ensuring stability and durability during extended use.
- Powerful Performance: Operates at ≥3000W, powered by an AC 220V ±10% supply for consistent and reliable production.
- Optimized Pneumatics: Requires air pressure of 0.4 MPa to 0.6 MPa for smooth and stable operation.
Technical Specifications:
- Spindles: 8 spindles for efficient multi-coil winding.
- Machine Dimensions: 1260mm x 1200mm x 1630mm, compact and suitable for various production environments.
- Weight: Approximately 850kg, providing stability and reduced vibration during operation.
Premium Components:
- Motion Control System: Guangdong Junyi ensures seamless operation and customization.
- Power Supply: Mingwei provides steady and reliable power.
- Bearings and Guides: High-precision components from NSK (Japan) and TBI (Taiwan) ensure smooth operation and longevity.
- Sensors and Switches: Integrated with OMRON sensors and magnetic switches from Taiwan Yadeke for enhanced safety and functionality.
- Belts: High-quality Mitsuboshi belts (Japan) ensure long-lasting performance.
