Key Features:
- 6-Axis Control System: Enables precise and synchronized winding operations, ensuring consistent and accurate results for a variety of coil designs.
- Flexible Wire Spacing: Features a spindle distance of 54mm, providing adaptability for different winding configurations.
- Wire Compatibility: Handles wire diameters ranging from 0.025mm to 0.5mm, accommodating both standard and intricate winding requirements.
- Robust Design: Supports a maximum bone frame diameter of 30mm with a main shaft diameter of 10mm, ensuring stability during high-speed operation.
- Powerful and Efficient: Operates at a power capacity of ≥3000W, powered by an AC 220V ±10% system, offering reliable and efficient performance.
- Optimized Pneumatics: Operates efficiently with a compressed air supply ranging from 0.4 MPa to 0.6 MPa, supporting smooth and reliable machine functions.
Technical Specifications:
- Spindles: 6 spindles for efficient and simultaneous winding.
- Machine Dimensions: 1260mm x 1200mm x 1630mm, compact for optimized workspace utilization.
- Weight: Approximately 850kg, providing stability during operation.
Premium Components:
- Control System: Guangdong Junyi for advanced motion control.
- Power Supply: Mingwei for stable and consistent power output.
- Bearings and Guides: High-quality components from NSK (Japan) and TBI (Taiwan) ensure smooth and precise motion.
- Sensors and Switches: Integrated with OMRON sensors and magnetic switches from Taiwan Yadeke for enhanced safety and performance.
- Belts: Durable and long-lasting Mitsuboshi belts (Japan).
